特點及應用| Characteristics and Application

　　應用于縫紉線、繡花線、松筒色紗、織帶等紡織用紗線。具有高卷速，產量大，產品成型平整，換卷方便快捷，易損件少，能耗低等優點。

　　技術參數：

　　卷繞機繞絲線速度：250m/min

　　電源：AC380V  50HZ

　　電機功率：500W

　　連接電纜3×2.5   R.S.J.MP

　　卷繞筒管尺寸： Φ94（內徑）×Φ104（外徑）×290（長度）

　　卷繞成型尺寸：Φ0-250MM-250MM

　　往復行程：250mm

　　單錠面板尺寸：寬×高475×330

　　Applied to sewing thread, embroidery thread, matting yarn, woven ribbon and other textile yarn.It has high volume speed, large output, smooth formation of products, easy to change volume, less vulnerable parts and low energy consumption.

　　Technical parameters:

　　Winding speed：250m/min

　　Power：AC380V  50HZ

　　Motor power：500W

　　Connect the cable：3X2.5  R.S.J.MP

　　Winding bobbin size：Inside diameter x Outside diameter x length（mm）94X104X290（The inner diameter and length have different requirements can be customized in the range）

　　Winding the size：Φ0-250MM-250MM

　　Reciprocating stroke：250mm

　　Single spindle panel size：Wide x high（mm）475X330
